Rotronic Cleanroom Panel CRP5 for Reliable Measurement in Clean Rooms

The new Clean Room Panel is fitted with a diaphragm sensor and validated according to GMP directives. Its well thought-out design makes the CRP5 perfect for applications in laboratories and clean rooms.

The CRP5 clean-room panel is the obvious choice wherever a high degree of cleanliness is vital, in addition to precise measurement of differential pressure, humidity, and temperature. Optical buttons, and the magnet-mounted, removable HC2-CRP humidity and temperature probe permit efficient and effective cleaning.

Up to six measurement values and messages can be displayed via its graphical colour display. The colors of the display can be adjusted individually. Alarms, such as faults, exceeded limit values, or warnings are highlighted on the CRP5 display, and can also be forwarded digitally via MODBUS, Ethernet, or relays. Thanks to its analog and digital communication capabilities, the CRP5 is very easy to integrate in any monitoring system and a large variety of measuring instruments, for example, for dew point, CO₂ and flow, but also other devices (like door contacts) can be attached.

The CRP5 is used particularly in clean-rooms in hospitals, in the pharmaceutical, electronics, and foodstuffs industries, and wherever small variances in pressure are monitored. The very comprehensive functional capabilities of the CRP5 provide solutions for many measurement and control tasks.

Features at a glance

• Measures differential pressure, humidity and temperature
• Designed specifically for clean rooms
• Removable humidity and temperature probes for simpler adjustment and cleaning
• FDA- and GAMP-compatible
• Digital communication via Ethernet RJ45 and/or MODBUS TCP / RTU
• Analog input and output signals freely configurable
• Glass front panel highly resistant to chemicals
• Optical operating elements for operation with protective gloves.

For further information on the CRP5 and other Rotronic instruments, please visit the website or call +41 44 838 11 44.
