Hamilton has greatly improved the cleanability of armatures/holders mounted in 25mm G1-1/4 ports with the HyCIPTM process connection. This patent pending design provides excellent cleaning, high sterile security and extremely safe handling. There is a variety of process
connections available such as HyCIPTM, Varivent, BioConnect, Triclamp and more!
The advantages of the RETRACTEX are:
• Extremely compact and designed for long life with 12 x 225 mm shaft, PG13.5 sensors
• 100% isolation of the pneumatic motor and the wetted parts
• The sensor window can be directed into or away from the process stream
• Quick disconnection of the cleaning ports (clamps)
• With HyCIP™ you also clean the space between the 25 mm port and the armature
• All wetted parts are FDA/USP compliant
This armature is compatible with all pH, conductivity and oxygen
measurements in difficult or hygienically high demanding application. The armature fulfills the requirement of ATEX.
