Huber Introduces Petite Fleur - The Baby Tango

The baby Tango is the entry level model for temperature control applications in the mid-range -40°C to 200°C.

The Tango is the original and smallest circulator of the Unistat® range, which has been the benchmark for many years. The Tango and the Unistats® are suitable for externally open baths or closed applications, e.g. reactors. The first version of ‘Petite Fleur’, the baby Tango, is designed for externally closed applications. With the expansion tank and the large illuminated sight glass, it is instantly recognisable as a Unistat® with

all the well known advantages. A second version for open bath applications is in preparation. The bigger Unistat® models are equipped with the 5,7” display, and the baby tango welcomes the user with 3,5” display of the CC-Pilot.

Functionality for all Applications

As with the large Unistats® the ‘Petite Fleur’ comes with full controller functionality. The powerful variable speed pump combined with the VPC pressure control and the TAC adaptive internal and cascade control unsure the best possible results. The "Professional" E-grade and an internal ComBox are factory installed as standard.

Easy to handle

Just 260 mm wide the baby Tango is ideally suited to fit in extraction hoods and fume cupboards. The castors fitted at the back of the unit allow it to be easily positioned. If the application is regularly changed, residual water in hoses and reactors can be a problem. The water mixes with the thermal fluid and inhibits the heat transfer process. The new water separation system allows water to be removed from the thermal fluid during thermal regulation.

More Power

Reducing the pump speed reduces the heat energy entering the system. This leads to higher cooling powers and lower end temperatures. The baby Tango has an

unusually powerful pump. Reducing the pump speed can make additional cooling power available - an extra 30 to 50 Watts can be achieved.

The introduction of the ‘Petite Fleur’ now means that the Unistat® temperature control system is available with a cooling capacity from 480 Watts at 20°C, making it

the only temperature control system in the world which offers professional Scale-Up from small scale laboratory R&D through to production plant. The Unistat®

temperature control system covers a temperature range from -120°C to 400°C and cooling and heating powers up to 130 kW. Huber.
